BS-GSP Series

Multi-Port Gigabit PoE Smart Switches. With Gigabit speeds, advanced management features, the convenience of Power over Ethernet and 8, 16 or 24 ports.

Product Data Sheet

BS-GSP Series

Multi-Port Gigabit PoE Smart Switches. With Gigabit speeds, advanced management features, the convenience of Power over Ethernet and 8, 16 or 24 ports.

Buffalo’s Multi-Port Gigabit PoE Smart Switches provide a host of comprehensive HTTP/HTTPS web-based network management features including VLAN, SNMP, port trunking/link aggregation, DHCP snooping, STP support and 802.1p QoS. Along with 802.3az Green Ethernet technology, the BS-GSP Series includes an energy conservation feature that monitors the activity status of each port to reduce the total power consumed. Gigabit speeds, eco-minded operation, performance-minded features and a lifetime warranty make Buffalo’s BS-GSP Series of Multi-Port Gigabit PoE Smart Switches a perfect network extension solution for your office.

Number of Ports

8, 16 or 24 LAN

Bandwidth

16, 32, 48 Gbps

PoE Budget

30 W / port, Max 90 W (BS-GS2008P), Max 180 W (BS-GS2016P & BS-GS2024P), Mode A

Buffer memory

1,5 MB

Durable high temperature

Durable metal chassis and reliable design make it possible to be used under 50°C temperature. It can be used in various places such as the ceiling back of office, warehouse, factory…

Lifetime warranty

Buffalo’s high quality level delivers lifetime warranty. As long as the customer, who has registered within 90-days from purchase date, owns the product, we will replace the product for hardware failure replacement any time within the period. Read more

Network QuickView for easy monitoring

Buffalo Network QuickView software supports this product for managing and setting up multiple devices simultaneously, such as Switches or TeraStation.

Power over Ethernet

Using PoE means getting supply power to network devices with an ethernet cable over the existing data connection.

With PoE you use one cable for both power and data transmission and this way you save money on purchasing and running cable for networking equipment and surveillance cameras
You can easyly and cheaper install and expand a network in buildings
With PoE you reduce the number of cables and electrical outlets needed

Network specification

Supported Standards

IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T), IEEE802.1D Spanning Tree Protocol, IEEE802.1w Rapid Spanning Tree Protocol, IEEE802.1p Class of Service, Priority Protocol, IEEE802.1Q VLANs, IEEE802.3ad (LACP), IEEE802.3az, AUTO-MDIX

Number of Ports

8, 16 or 24 LAN

Data transfer rate

1000 Mbps (1000 BASE-T), 100 Mbps (100 BASE-TX), 10 Mbps (10 BASE-T), 1Gbps

Bandwidth

16, 32, 48 Gbps

Buffer memory

1,5 MB

Loop prevention

yes

VLAN feature

yes

QoS

yes

Port Trunking

yes

PoE Budget

30 W / port, Max 90 W (BS-GS2008P), Max 180 W (BS-GS2016P & BS-GS2024P), Mode A

Other

Power Consumption (max.)

10,6W (BS-GS2008P), 14,6W (BS-GS2016P), 18,6W (BS-GS2024P)

Product Part Numbers

Product Code

BS-GS2008P, BS-GS2016P, BS-GS2024P

Downloads

Product Data Sheet Product images

Manuals / Setup / Latest Product Information
Documentation & Software		BS-GS2008P	24-09-2018
Documentation & Software		BS-GS2016P	24-09-2018
Documentation & Software		BS-GS2024P	24-09-2018
Firmware
Release notes	1.0.3.47		10-06-2019
Firmware updater	1.0.3.47	All	10-06-2019
Utilities
MIB files for SNMP software			11-07-2018
Release Notes	2.1.0		09-01-2018
Business Switch Configuration Tool	2.1.0	Windows	09-01-2018
