BS-GUP Series

Buffalo’s BS-GUP series of multi-port gigabit PoE switches offer gigabit speeds and the convenience of Power over Ethernet.

Product Data Sheet

BS-GUP Series

Buffalo’s BS-GUP series of multi-port gigabit PoE switches offer gigabit speeds and the convenience of Power over Ethernet.

Plug and play installation requires no additional software or configuration; each auto-sensing gigabit port automatically detects and configures the correct connection while full duplex operation and optional jumbo frame support provide maximum performance. Buffalo’s multi-port gigabit switches include power saving features like 802.3az Green Ethernet technology and an energy conservation feature that monitors the activity status of each port to reduce the total power consumed, therefore reducing related operational costs. With 5, 8 or 16 ports. Gigabit speeds, eco-minded features and a lifetime warranty* make Buffalo’s BS-GU20xxP series of multi-port gigabit switches a perfect network extension solution for your office.

Number of Ports

5, 8, or 16

Bandwidth

10, 16, 32 Gbps

PoE Budget

15,4 W/port, Max 50W (BS-GU2005 & BS-GU2008P) Max 120W (BS-GU2016P)

Buffer memory

128 KB, 256 KB, 512 KB

Durable high temperature

Durable metal chassis and reliable design make it possible to be used under 50°C temperature. It can be used in various places such as the ceiling back of office, warehouse, factory…

Lifetime warranty

Buffalo’s high quality level delivers lifetime warranty. As long as the customer, who has registered within 90-days from purchase date, owns the product, we will replace the product for hardware failure replacement any time within the period. Read more

Power over Ethernet

Using PoE means getting supply power to network devices with an ethernet cable over the existing data connection.

With PoE you use one cable for both power and data transmission and this way you save money on purchasing and running cable for networking equipment and surveillance cameras
You can easyly and cheaper install and expand a network in buildings
With PoE you reduce the number of cables and electrical outlets needed

USB interface

Connector Type

RJ-45

Network specification

Supported Standards

IEEE802.3 (10BASE-T) IEEE802.3u (100BASE-TX) IEEE802.3ab (1000BASE-T), AUTO-MDIX

Number of Ports

5, 8, or 16

Data transfer rate

1000 Mbps (1000 BASE-T), 100 Mbps (100 BASE-TX), 10 Mbps (10 BASE-T), 1Gbps

Bandwidth

10, 16, 32 Gbps

Buffer memory

128 KB, 256 KB, 512 KB

Loop prevention

yes

PoE Budget

15,4 W/port, Max 50W (BS-GU2005 & BS-GU2008P) Max 120W (BS-GU2016P)

Other

Power Consumption (max.)

Max 61W (BS-GU2005P) Max 60W (BS-GU2008P) Max 148W (BS-GU2016P)

Product Part Numbers

Product Code

BS-GU2005P BS-GU2008P BS-GU2016P
